MFJ Antenna Analyzer

Quick Reference Guides

  Nifty! Guides for the MFJ-225, MFJ-259B,  MFJ-266  &  MFJ-269 Analyzers

Simplified Operating Instructions and Explanations

   Perfectly sized to fit in the analyzer's box or carrying case!

Nifty! MFJ 269 analyzer operating guide

The Finest MFJ  Reference Guides Available

Operating modes clearly explained

Antenna Adjustment Hints and Issues

SWR Measurement Accuracy Issues

Measuring Cable Losses

Distance to Fault

Measure Capacitance and Inductance

Frequency Counter Operation

Preventing instrument damage

Battery & External Power Supply operation

Advanced Mode operations



Short Form Manual, Fast and Easy to use.

Simplified operating instructions for quick and efficient analyzer operation.

Eight pages, Laminated & Bound for durability.



Compact: Small and rugged enough to be kept with the analyzer -- so its always there as a quick reference when you need it.



           High Quality & Durable

Comes as a 8 page spiral bound manual
At 4.5 x 8 inches, its about the same size as the analyzer.
With the same footprint, its easily kept in the analyzer's case
Ideal for use while operating home QTH, Field Day or portable
Laminated for improved Durability and Water Resistance
High quality color printing for greater clarity
Organized to find what you need fast
Never again be without a ready reference when its needed.

An invaluable aid for quickly recalling how to use your analyzer!

Ideal Short Form Guide for Portable and Home QTH operations.

  MFJ-225  Mini-Manual $12.95 ea

   MFJ-225 Mini-manual.  Size, 4.5 x 8 inches. Eight high-quality laminated pages.  Complete short form operating instructions in a compact reference guide. Ideal as a ready reference and memory jogger for making graphical antenna SWR, impedance, phase angle, return loss, inductance, capacitance versus frequency measurements. How to perform coaxial cable integrity tests, tune stubs and the measurement of capacitors and inductors are also covered.  Two different PC programs are described for taking full advantage of the analyzer's Vector Network Analyzer capabilities and the saving and printing out of various graphical antenna parameter scans.

            MFJ-225 Mini-Manual Quantity:

MFJ 259B operating guide

  MFJ-259B  Mini-Manual $12.95 ea

MFJ-259B Mini-manual.  Size, 4.5 x 8 inches. Eight high-quality laminated pages.  Complete short form operating instructions in a compact reference guide. Ideal as a ready reference and memory jogger for making SWR, impedance, inductance, capacitance, frequency and other measurements.

            MFJ-259B Mini-Manual Quantity:

MFJ 269 operating guide

  MFJ-266 /B /C  Mini-Manual $12.95 ea

MFJ-266  Mini-manual.  This guide covers the operation of all three MFJ-266 models: the original -266 and the "B" and "C" models.  The "B" model added an optional rechargeable battery and the "C" model extend the frequency range to cover the 220 MHz band. Size, 4.5 x 8 inches. Eight high-quality laminated pages.  Complete short form operating instructions in a compact reference guide. Ideal as a ready reference and memory jogger for making SWR, impedance, inductance, capacitance, frequency and other measurements.

MFJ-266 /B /C  Mini-Manual Quantity:

MFJ 269 operating guide

  MFJ-269 and MFJ-269PRO  Mini-Manual $12.95 ea

MFJ-269 & MFJ-269PRO Mini-manual.  Size, 4.5 x 8 inches. Eight high-quality laminated pages.  Single guide covers both analyzers.  Complete short form operating instructions in a compact reference guide. Ideal as a ready reference and memory jogger for making SWR, impedance, inductance, capacitance, frequency and other measurements.

MFJ-269 & 'PRO Mini-Manual Quantity:
